| Type | LM-2020F |
| Power | 20W /30W/50W |
| Laser Brand | Raycus (Maxphotonics/IPG Optional) |
| Marking Area | 110mm*110mm |
| Optional Marking Area | 110mm*110mm/150mm*150mm/200mm*200mm |
| Marking Depth | ≤0.5mm |
| Marking Speed | 7000mm/s |
| Minimum Line Width | 0.012mm |
| Minimum Character | 0.15mm |
| Repeated Precision | ±0.003mm |
| Life-span of Fiber Laser Module | 100 000hours |
| Beam Quality | M2 <1.5 |
| Focus Spot Diameter | <0.01mm |
| Output Power of Laser | 10%~100% continuously to be adjusted |
| System Operation Environment | Windows XP / W7–32/64bits / W8–32/64bits |
| Cooling Mode | Air cooling–Built-in |
| Temperature of Operation Environment | 15℃~35℃ |
| Power Input | 220V / 50HZ / single phase or 110V / 60HZ / single phase |
| Power Requirement | <400W |
| Communication Interface | USB |
| Package Dimension | 720mm x 460mm x 660mm |
| Gross weight | 58KG |
| Optional (Not free of charge) | Rotary Device, Moving Table, other customized Automation |
